| 参数 | SPECIFICATION | 技术指标/TECHNIQUE |
| 额定量程 | CAPACITY | 70Nm |
| 激励电压 | RECOMMENDED EXCITATION | 5-5.5V |
| 产品精度 | PRODUCT ACCURACY | ≤0.5%F.S. |
| 工作温度范围 | OPERATING TEMP RANGE | -20-100°C |
| 补偿温度范围 | COMPENSATION TEMP RANGE | -10-80°C |
| 极限侧向力 | ULTIMATE LATERAL FORCE | 3000N |
| 极限弯矩 | ULTIMATE BENDING MOMENT | 110Nm |
| 安全过载 | SAFE OVERLOAD | 200%F.S. |
| 极限过载 | ULTIMATE OVERLOAD | 300%F.S. |
| 重量 | MASS | 0.550kg |
| 扭转角度( 计算 ) | TORSION ANGLE(CALCULATED | 0.04° |
| 扭转刚度 | TORSIONAL STIFFNESS | 100kNm/Rad |
| 线缆规格 | CABLE SPECIFICATION | Φ3x300mm |
| 信号形式 | SIGNAL FORM | 数字信号( 485通信 ) |
| 防护等级 | LEVEL OF PROTECTION | lP65 |
