| 额定量程 | CAPACITY | 126Nm |
| 供电电压 | RECOMMENDED EXCITATION | 5V |
| 产品精度 | PRODUCT ACCURACY | ≤0.5%F.S. |
| 工作温度范围 | OPERATING TEMP RANGE | 0-80°C |
| 补偿温度范围 | COMPENSATION TEMP RANGE | 室温~60℃℃ |
| 极限侧向力 | ULTIMATE LATERAL FORCE | 5000N |
| 极限轴向力 | ULTIMATE AXIAL FORCE | 3500N |
| 极限弯矩 | ULTIMATE BENDING MOMENT | 80Nm |
| 安全过载 | SAFE OVERLOAD | 150% F.S. |
| 极限过载 | ULTIMATE OVERLOAD | 200% F.S. |
| 重量 | MASS | 0.5kg |
| 扭转角度(计算) | TORSION ANGLE(CALCULATED) | 0.023° |
| 扭转刚度 | TORSIONAL STIFFNESS | 31 1kNm/Rad |
| 线缆规格 | CABLE SPECIFICATION | Φ3×1m黑色四芯线 |
| 信号形式 | SIGNAL FORM | 数字信号（485通信） 460800-28Bytes，1000Hz |
| 防护等级 | LEVEL OF PROTECTION | IP65 |
