| 额定量程 | CAPACITY | 40Nm |
| 激励电压 | RECOMMENDED EXCITATION | 9-24V |
| 产品精度 | PRODUCT ACCURACY | <0.5%F.S. |
| 工作温度范围 | OPERATING TEMP RANGE | -0-80°C |
| 补偿温度范围 | COMPENSATION TEMP RANGE | 0-60°C |
| 极限侧向力 | ULTIMATE LATERAL FORCE | 5000N |
| 极限弯矩 | ULTIMATE BENDING MOMENT | 20Nm |
| 安全过载 | SAFE OVERLOAD | 200% F.S. |
| 极限过载 | ULTIMATE OVERLOAD | 300% F.S. |
| 重量 | MASS | 0.250kg |
| 扭转角度(计算) | TORSION ANGLE(CALCULATED) | 0.04° |
| 扭转刚度 | TORSIONAL STIFFNESS | 57kNm/Rad |
| 线缆规格 | CABLE SPECIFICATION | 中3x500mm |
| 信号形式 | SIGNAL FORM | 数字信号(485通信) |
